Sampler Plugin Developer Documentation

Section 1: Threading Overview

Execution Context

Plugin interfaces (constructor(), config(), sample(), destructor()) are not always called from the same thread. Understanding which thread calls which interface is important because it determines what operations are safe to perform and whether additional synchronization is needed. ldmsd uses three categories of threads:

Worker threads are created and managed by ldmsd. Their responsibilities are:

• Schedule samples

• Call sample()

• Handle configuration commands (load, config, start, stop, term) in configuration files either from -c or -y

Dedicated sampling thread — if the plugin instance is configured to use a dedicated thread, ldmsd creates one when start is called and deletes it when stop is called. Its sole responsibility is to call sample() for that plugin instance.

IO threads (also referred to as transport threads) are created and managed by Zap. Their responsibilities are:

• Handle configuration commands (load, config, start, stop, term) sent by a remote interface (ldmsd_controller and maestro)

• Deliver Stream and Message to sampler plugins

Section 2: API Threading Guarantees

Each plugin interface may be called by different threads depending on how the command that triggers it is delivered — whether from a configuration file processed at startup or from a remote client such as ldmsd_controller or maestro. The following describes which thread is responsible for calling each interface.

Config Commands to Sampler Plugin Interface Calls

• constructor() is called by the thread handling the load configuration command:

  • worker thread when the load command is in config files

  • IO thread when the load command is sent by a remote client such as ldmsd_controller or maestro

• usage() is called by the thread handling the usage configuration command:

  • IO thread typically calls usage() because it makes most sense for users to use it in ldmsd_controller

  • usage() is expected to return an immutable string of a short description of the plugin and how to configure it

• config() is called by:

  • worker thread when the command is in config files

  • IO thread when the command is sent by a remote client such as ldmsd_controller or maestro

• sample() is only called by a single thread:

  • a worker thread shared with other ldmsd’s operations (e.g., other sampler plugin’s sample() calls)

  • a dedicated thread created by ldmsd at the config time if the plugin instance is configured to have a dedicated sampling thread

• destructor() can be called by either a worker thread or an IO thread. It is called when the reference of the plugin configuration object reaches zero.

Beyond knowing which thread calls which interface, plugin authors can rely on a set of ordering and availability guarantees that ldmsd enforces across the plugin lifecycle. These are safe to assume regardless of which thread is active:

What Sampler Plugin Authors CAN Assume

• constructor() will be the first interface to be called

• destructor() will be the last interface to be called

• Plugin instance log handle is available when constructor() is called, so ldmsd_plug_log_get() can be called in constructor()

• The plugin instance log handle exists when destructor() is called

• The plugin instance has been configured at least once (config name=<plugin instance name> ...) before sample() is called

• All plugin interfaces are protected by mutex, except usage(), which may be called concurrently with config() and sample()

Section 3: Concurrency Scenarios

This section describes which plugin operations can run concurrently and which are mutually exclusive. ldmsd serializes most plugin operations to prevent race conditions. usage() is the exception — it is not serialized because it only returns an immutable string and therefore does not modify any plugin state.

Concurrent Operations

usage() may run concurrently with the other operations between constructor() and destructor() calls.

Mutually Exclusive Operations

constructor(), config(), sample(), and destructor() are mutually exclusive. All these operations are serialized by ldmsd — only one executes at a time.

Section 4: Synchronization Mechanism

This section describes how to write thread-safe sampler plugins. It covers two distinct mechanisms: plugin-level locking for protecting plugin-owned data when the plugin manages its own threads, and the LDMS set transaction API for protecting metric consistency during updates.

Guidance for Plugin Authors

Sampler plugin authors do not need locks to synchronize between plugin operations (constructor(), config(), sample(), destructor()) because ldmsd serializes all these operations — only one executes at a time. Plugin authors need to use locks if and only if the plugin itself has multiple threads of execution.

What Locking Primitives to Use

• Use standard pthread_mutex_t for protecting plugin-owned data

• Do NOT attempt to use ldmsd’s internal cfgobj lock

• Initialize mutex in constructor(), destroy in destructor()

Lock Order Guideline

• If your plugin uses multiple locks, document your own lock acquisition order

• Never call ldmsd APIs (like ldmsd_set_deregister) while holding plugin locks

• Be mindful of holding locks for unnecessary duration to optimize the sampler plugin performance

• Release all plugin-specific locks before returning any interfaces

When Locks Are NOT Needed

• Protecting data that is only accessed by plugin operations (constructor(), config(), sample(), destructor())

• Changing metric values in LDMS sets do not need any locks

LDMS sets do not require explicit locking by plugin authors — thread safety is handled by the transaction API.

Thread Safety of LDMS Sets

• LDMS sets have built-in transaction safety via “consistent/inconsistent” flags

• sample() must call ldms_transaction_begin() before updating a metric value and call ldms_transaction_end() after updating all metric values

• Set readers can call ldms_set_is_consistent() to verify that a set is not currently being updated

• Sampler plugin authors do NOT need additional locks for the LDMS set data itself

• LDMS transaction APIs are only needed to enable external set readers to verify inconsistent metric values. For example, an ldmsd aggregator automatically checks if the set is inconsistent so that it will not store a set that is in the inconsistent state

Available Locks

Do not call ldmsd_cfgobj_lock(). The cfgobj lock protects internal ldmsd properties. Sampler plugin authors should not use or depend on this lock. Use pthread_mutex_t for plugin data.

Section 5: Plugin Lifecycle

This section describes the lifecycle of a sampler plugin instance. A plugin instance transitions through a defined set of states in response to configuration commands. The state determines which plugin interfaces ldmsd may call and which commands are valid at that point. Note that a plugin instance must be stopped before it can be terminated — the term command is only valid from the INIT or CONFIGURED states.

State Diagram

Sampler Plugin Lifecycle State Diagram

State Descriptions

The table below describes each state in the plugin lifecycle, how it is entered, and which operations are permitted in that state.

State	How to Enter	Plugin Status	Allowed Operations	Operation Calling Thread
INIT	load command calls constructor()	Plugin loaded but not configured	config(), usage()	Worker or IO
CONFIGURED	config command calls config(), or stop command after start command	Plugin configured	config() (reconfig & multi-config lines), usage()	Worker or IO
RUNNING	start command initiates sampling	Plugin actively sampling data	sample(), usage()	Worker or dedicated sampling thread (for sample()); IO (for usage())
TERMINATING	term command	Plugin being destroyed	destructor()	Worker or IO (whoever drops last reference)

Section 6: Using the LDMS Message Service in Sampler Plugins

Terminology

LDMS Message Bus (declared in ldms_msg.h, API prefix ldms_msg_)

The pub/sub routing layer in LDMS. Each message is published with a tag name; subscribers register callbacks against a tag name or regex pattern to receive matching messages. The Message Bus manages the routing and delivery of messages to authorized subscribers. See ldms_msg(7).

Message channel (declared in ldms_msg_chan.h, API prefix ldms_msg_chan_)

A resilient mechanism that sits on top of the LDMS Message Bus. A message channel manages multiple message buses, reconnects if a peer disconnects, and queues data while the peer is down. See ldms_msg_chan(7).

Checking Whether the Message Service Is Enabled

Both APIs require the message service to be enabled. Check with ldms_msg_is_enabled() before using either API:

if (!ldms_msg_is_enabled()) {
    /* handle disabled case */
}

How to handle a disabled message service depends on the plugin:

• If the plugin requires the message service to function at all, return an error from constructor() to prevent the plugin from loading.

• If the plugin has modes that do not use the message service, return an error from config() only when the user configures a mode that requires it.

Plugins must not call ldms_msg_enable() to enable the service themselves. Whether the message service is enabled is an ldmsd instance-level decision, not a per-plugin one.

Which API to Use

The choice depends on whether the plugin needs to own a connection to a peer.

A plugin that relies on connections already managed by ldmsd uses the LDMS Message Bus API (ldms_msg_) directly — no connection management required.

A plugin that needs its own dedicated and reliable connection to a peer — whether connecting out to a remote peer or listening for incoming connections — uses the message channel API (ldms_msg_chan_).

Use case	API to use
Plugin does not need to own a connection	ldms_msg_subscribe() and/or ldms_msg_publish(NULL, ...)
Plugin needs to own a connection to a peer	ldms_msg_chan

Key points:

• Within each case, the plugin can subscribe, publish, or both as needed.

• A single message channel can publish on any number of different tag names. A plugin needs at most one channel per peer.

• Without a message channel, if the peer the plugin depends on disconnects, there is no reconnect logic and the plugin will not recover.

• A plugin that needs to own a connection only for subscribing should be aware that ldms_msg_chan in subscribe mode creates a listening transport endpoint bound to a local port. This is appropriate for plugins that act as a passive listener for an incoming publisher connection.

Appropriateness by Plugin Interface

The following table summarizes which functions are appropriate to call from each plugin interface. For threading details and what is safe to call from within the callback, see ldms_msg(7) and ldms_msg_chan(7).

API	constructor()	config()	sample()	destructor()	callback
ldms_msg_subscribe()	Yes	Yes	Not appropriate [1]	Not appropriate [1]	Yes
ldms_msg_client_close()	No	Yes	Not appropriate [1]	Yes	Yes
ldms_msg_publish(NULL,...)	Yes	Yes	Yes	No	Yes [2]
ldms_msg_chan_new()	Yes	Yes	Not appropriate [1]	No	No
ldms_msg_chan_publish()	No	Yes	Yes [3]	No	Yes
ldms_msg_chan_close()	No	Yes	Not appropriate [1]	Yes	Yes [4]
ldms_msg_chan_set_q_limit()	Yes	Yes	No	No	No

Notes

[1] (1,2,3,4,5)

Not a thread safety issue. These are lifecycle operations that belong in constructor() and config(), not in sample() or destructor() per call.

[2]

ldms_msg_publish(NULL, ...) invokes subscriber callbacks inline before returning. Avoid holding plugin-internal locks across this call inside a callback — see ldms_msg(7).

[3]

If adding the message would exceed the queue limit, ldms_msg_chan_publish() returns ENOBUFS. Adjust the queue limit with ldms_msg_chan_set_q_limit() if needed.

[4]

Avoid calling ldms_msg_chan_close() with cancel=0 from within the callback — it will block the IO thread for the duration of teardown. Use cancel=1 if closing from within a callback.

Callback

For the LDMS Message Bus API, the callback is invoked by whichever thread called ldms_msg_publish() for messages published on the same bus, or by an IO thread for messages arriving from a remote peer. The LDMS_MSG_EVENT_CLIENT_CLOSE event is delivered to signal that teardown is complete and resources may be freed.

For the message channel API, the callback is always invoked by an IO thread. LDMS_MSG_EVENT_CLIENT_CLOSE is handled internally by the channel and is not delivered to the application callback.

For full details on callback threading, what is safe to call, and teardown patterns, see ldms_msg(7) and ldms_msg_chan(7).

Section 7: LDMSD Internal Implementation Details (For Maintainers Only)

This section documents ldmsd-internal implementation details for ldmsd maintainers. Plugin authors do not need to read this section.

Lock Acquisition Order

The following describes the acquisition order for the plugin cfgobj lock:

• Take when handling start; release before replying back

• Take before calling sample(); release after returning

• Take when handling stop; release before replying back

• Take when handling term:

  • Release before calling ldmsd_set_deregister()

  • Re-acquire the lock

  • Release before removing the cfgobj from the tree

SEE ALSO

ldmsd(8) ldmsd_controller(8) ldms_msg(7) ldms_msg_chan(7)
